Multi-Zone Cooling and Heating System

Multi Zone WMO

The WMO-MZO multi-zone system is a proven model. It is a good solution for those with a moderate budget who wish to air condition or heat several rooms at the same time.

The WMO-MZO multi-zone system can support a ratio of two to five indoor units per outdoor unit. Depending on your needs and installation constraints, it is even possible to mix different types of indoor units.

Product Highlights

18.000 - 42.000 BTU
16 SEER / 9 HSPF
Up to -20°C
Features

EFFICIENCY

  • 16 SEER cooling efficiency
  • 9 HSPF heating efficiency
  • OPERATIONAL RANGE:

  • Cooling mode - Min-Max of -5 °C ~ 43 °C
  • Heating mode - Min-Max of -20 °C ~ 24 °C
  • TECHNOLOGY

  • Inverter compressor
  • Compressor blanket and preheating technology
  • Heating wire in the defrost tray
  • Warranty

    The WMO-MZO multi-zone system has a 5-year basic warranty on parts and 5 years on the compressor.

     With our extended warranty programs, we can offer you up to 10 years on labour costs.

     Do not hesitate to ask your sales representative for more information when you request a quote.

    Documents available for download
    UNIT COMBINATION CHART
    Owner’s Manual

    Contact our team for more information about this model.

    Additional information

    The Multi-Zone systems are only offered in Air Conditioning & Heating. They are a good solution for homes heated with electric baseboard heaters, as they allow great savings on heating costs and offer greater comfort than radiant heating.

    Multi Zone MPD

    The MPD multi-zone system is ideal for cooling or heating several rooms at the same time. Energy Star certified, it will save you money on your heating bill in the winter and will keep you cool in the summer. In addition, each of the indoor units can be controlled individually for maximum comfort.

    The multi-zone MPD can support a ratio of two to five indoor units per outdoor unit. Depending on your needs and installation constraints, it is even possible to mix different types of indoor units.

    Product Highlights

    18.000 - 42.000 BTU
    22-21 SEER / 11 HSPF
    Up to -25°C
    Features

    EFFICIENCY

  • 22-21 SEER cooling efficiency
  • 11 HSPF heating efficiency
  • OPERATING RANGE

  • Cooling mode - Min-Max of -18 °C ~ 48 °C
  • Heating mode - Min-Max of -25 °C ~ 24 °C
  • TECHNOLOGY

  • Inverter compressor
  • ENERGY STAR® certified
  • Compressor blanket and preheating technology
  • Heating wire in the defrost tray
  • Warranty

    The MPD multi-zone system has a 5-year basic warranty on parts and 5 years on the compressor.

    With our extended warranty programs, we can offer you up to 10 years on labour costs.

    Do not hesitate to ask your sales representative for more information when you request a quote.

    Documents available for download
    Unit combination chart
    Owner’s manual
    Additional information

    Multi-Zone systems are only offered in Air Conditioning & Heating. They are a good solution for homes heated with electric baseboard heaters, as they allow great savings on heating costs and offer greater comfort than radiant heating.

    MPD24KCH21S-O, MPD30KCH21S-O and MPD36KCH21S-O are ENERGY STAR® and NEEP certified and eligible for financial assistance from Rénoclimat, Novoclimat and Chauffez Vert.

    Super Multi Zones

    The super multi-zone WMO-MZO system is as its name suggests a powerful outdoor unit that can operate eight to nine indoor units. It is the perfect solution if you want to cover your entire house or apartment with air conditioning and heating.

    Like the other models, it is possible to mix different types of indoor units according to your needs and installation constraints.

    Product Highlights

    48.000 - 56.000 BTU
    16 SEER / 9 HSPF
    Up to -20°C
    Features

    EFFICIENCY

  • 16 SEER cooling efficiency
  • 8.2 HSPF heating efficiency
  • OPERATING RANGE

  • Cooling mode - Min-Max of -5 °C ~ 48 °C
  • Heating mode - Min-Max of -20 °C ~ 24 °C
  • TECHNOLOGY

  • Inverter compressor
  • Heating wire in the defrost tray
  • Compressor blanket and preheating technology
  • 2 and 3 outlet connection port
  • Warranty

    The WMO-MZO multi-zone system has a 5-year basic warranty on parts and 5 years on the compressor.

    With our extended warranty programs, we can offer you up to 10 years on labour costs.

    Do not hesitate to ask your sales representative for more information when you request a quote.

    Documents available for download
    Unit combination chart

    Contact our team  for more information about this model.

    Manuel de l’utilisateur

    Contact our team  for more information about this model.

    Additional information

    Multi-Zone systems are only offered in Air Conditioning & Heating. They are a good solution for homes heated with electric baseboard heaters, as they allow great savings on heating costs and offer greater comfort than radiant heating.
